Hardi 12v polttoainepumppu UUSI
Tuotteen kuvaus
Kunto: Uusi
Uusi Hardi 18812 12v polttoainepumppu. Nämä tiedot netistä:
Suitable for car above 100 HP
For vehicles with carburettor as conveyor pump from tank to carburettor.
For pumping unleaded petrol, diesel and fuels containing methanol and ethanol
This pump also works well for the promotion of low media (eg vegetable oil) due to their construction and is therefore increasingly during the conversion of Diesel vehicles used on vegetable oil.
Features:
Pump capacity adjusts to consumption rate
Suitable for universal use and for each engine type
Easy to install (assembly instructions are enclosed)
Protected against corrosion, noise suppressed and maintenance-free
Long life-span
Technical information:
Voltage (V):12
Connection (mm): 8
Capacity (l/min): 100-130
Temperature range (°C): -40 +80
Pressure (bar):0,28-0,35
Pumping height max. (m): 1
Power: 1,5-1,9A
Manufacturer Part Number: Hardi 18812
Easy to install
The pump must be protected against splash water.
Maximum flowrate of the pump will be obtained by mounting the pump at fuel tank level. To achieve the specified values, the maximum suction lift is approx. 1m
Make sure the voltage that is embossed into or printed on the housing of the pump corresponds to the voltage of the vehicle.
Horizontal or vertical mounting of the pump is possible at the vehicle. Mounted horizontally the fuel outlet must face upwards (see labelling on the pump’s cover
Connect the pump electrically with the housing connections. The connection must be made in such a way that the pump is supplied with current only when the ignition is started.
