Willem ohjelmoija
Myydään
ToriDiili
15 €
Toimitus alkaen 1,49 € + ToriDiili-palvelumaksu 2 €. Toimituskulut normaalisti 2,99 €.
Shoppaile ToriDiilillä kuin verkkokaupassa
ToriDiili on Torin uusi maksu- ja kuljetuspalvelu. Toimituksen jälkeen sinulla on 24 tuntia aikaa tarkastaa tuote ennen kuin rahat siirretään myyjälle.
Tuotteen kuvaus
Kunto: Uusi
Tyyppi: Muut
Paketista purettu, mutta käytännössä uusi rinnakkaisporttia käyttävä SPI 25xx PCB5.0T-2023 Willem ohjelmoija. Tilattu 5.9.2025. Virrat syttyy normaalisti, mutta ohjelmoimista en valitettavasti ole päässyt vanhan liitännän takia testaamaan. Saa virtoihin joko USB-B -kaapelilla tai ulkoisella virtalähteellä. Mukaan USB-B- sekä rinnakkaiskaapeli, SOIC-DIP 8-pinninen adapteri, työkalu komponenttien kannasta nostamista varten ja 5-pinninen kaapeli.
Tukee seuraavanlaista laitteistoa:
EPROM
27C64, 27C128, 27C256, 27C512, 27C010, 27C020, 27C040, 27C1001
M27C1001, M27C2001, M27C4001
27C080 (A19) , M27C801, M87C257
27(C)16, 27(C)32
2764, 27128, 27256, 27512, 27010
EEPROM
28C65,28C64, 28C128, 28C256,28C512, 28C010, 28C020, 28C040
M28C16A/17A (DIP28)
(Adapter or Jumper) 28C16,XLS2816 (DIP24)
FLASH Memory
28F64, 28F128, 28F256, 28F512,28F010, 28F020
MX26C1000, MX26C2000, MX28F1000, MX28F2000
Am28F256A, Am28F512A, Am28F010A, Am28F020A (New command erase/prog.)
-- intel ---
i28F001BX, 28F004, 28F008, 28F016
FLASH Memory
29F64, 29F128,29F256, 29F512,29F010, 29F020, 29F040, 29F080
29F001,29F002, 29F004, 29F008, 29F016, 29F032
Serial (I2C) EEPROM
24Cxx
24C02,24C04,24C08,24C16, 85C72, 85C82, 85C92
--- page write ----
24C32,24C64,24C128,24C256,24C512
Microwire EEPROM
<------ Data 8bit -----> (pin 6 ->ORG. [Schematic connect to GND])
93C06, 93C46, 93LC46, 93C56, 93C57,
93C66, 93C76, 93C86 (8bit), AT59C11, AT59C22, AT59C13
CAT35C102, CAT35C104, CAT35C108 (pullup pin7)
<------Data 16bit------> (pin 6 ->NC [No Connect])
93C06A ,93C46X,93C56,93C66,93C76,93C86 (NS)
MicroChip PIC
16C84 , 16F84 ,16F84A , 16F627/16F628
12C508/A , 12C509/A , 12CE518 , 12CE519 , 16C505
16C620 , 16C621 , 16C622 , 16CE623 , 16CE624 , 16CE625 , 16C710/711
---ICSP connector----(you will need to have an optional PIC adapter in order to program these newly added PICs)
16F870 , 16F871 , 16F872 , 16F873 , 16F874 , 16F876 , 16F877 PIC16F873A , PIC16F874A , PIC16F876A , PIC16F877A
-Add PIC microchip 14bit
PIC12F629 , PIC12F675 , PIC16F630 , PIC16F676 , PIC12F635 , PIC12F683 , PIC16F636 , PIC16F684 , PIC16F688
PIC16F72/73/74/76/77 , PIC16F737/747/767/777 , PIC16F87/88 , rfPIC12F675x , PIC16F785/PS200 , PIC16F716
-Add microchip 14bit,12bit OTP
PIC12C671 , PIC12C672 , PIC12CE673 , PIC12CE674
PIC16C61/71 , PIC16C62/64/65/73 , PIC16C62A/62B/62C/63/63A/64A/65A/65B/66/67
PIC16C72/72A/73A/74A/74B/76/77 , PIC16C620/620A/621/621A/622/622A
PIC16CE/623/624/625 , PIC16C710/711/712/716 , PIC16C773/774 , PIC16C745/765/923/924 , PIC16C925/926
PIC16C554/556/557/558 , PIC16C432/433 , PIC16C717/770/771/781/782
-Add PIC microchip 14bit
PIC12F629/675 , PIC16F630/676 , PIC12F635/683 , PIC16F636/684/688 , PIC16F72/73/74/76/77 , PIC16F737/747/767/777 , PIC16F87/88 , rfPIC12F675x , PIC16F785/PS200 , PIC16F716
-Add microchip 14bit OTP
PIC12C671 , PIC12C672 , PIC12CE673 , PIC12CE674 , PIC16C61/71 , PIC16C62/64/65/73 , PIC16C62A/62B/62C/63/63A/64A/65A/65B/66/67 , PIC16C72/72A/73A/74A/74B/76/77 , PIC16C620/620A/621/621A/622/622A , PIC16CE/623/624/625 , PIC16C710/711/712/716 , PIC16C773/774 , PIC16C745/765/923/924 , PIC16C925/926 , PIC16C554/556/557/558 , PIC16C432/433 , PIC16C717/770/771/781/782
-Add PIC microchip 12bit (FLASH memory)
PIC12F508/509 , PIC10F200/202/204/206 , PIC16F505 , PIC16F54/57
-Add PIC18Fxxx
PIC18F242 , 18F248 , 18F252 , 18F258 , 18F442 , 18F448 , 16F452 , 16F458
PIC18F1220 , 18F2220 , 18F4220 , 18F1320 , 18F2320 , 18F4320
PIC18F6520 , 18F6620 , 18F6720 , 18F8520 , 18F8620 , 18F8720
PIC18F2331 , 18F2431 , 18F4331 , 18F4431
PIC18F6525 , 18F6621 , 18F8525 , 18F8621
PIC18F6585 , 18F6680 , 18F8585 , 18F8680
PIC18F2439 , 18F2539 , 18F4439 , 18F4539
PIC18F6410 , 18F8410 , 18F6490 , 18F8490
Add PIC18Fxxx
PIC18F2410 , PIC18F2420 , PIC18F2455
PIC18F2510 , PIC18F2515 , PIC18F2520 , PIC18F2525 , PIC18F2550 , PIC18F2585
PIC18F2610 , PIC18F2620 , PIC18F2680
PIC18F4410, PIC18F4420 , PIC18F4455
PIC18F4510 , PIC18F4515 , PIC18F4520 , PIC18F4525 , PIC18F4550 , PIC18F4585
PIC18F4610 , PIC18F4620 , PIC18F4680
Add Find and edit value OSCCAL (PIC12F629/675 , PIC16F630/676)
Add Edit config at address 0x2008,0x2009 (PIC12F635/683 , PIC16F636/684/688 , PIC16F785)
Fixed Programming PIC all
Test on chip
PIC12F675 , PIC16F676 , PIC16F684 ,PIC16F767, PIC16F74
PIC16F872 , PIC16F876 , PIC16F877, PIC16F876A, PIC16F873A, PIC16F819
PIC16F84 , PIC16F84A , PIC16F628, PIC16F628A,
eprom PIC12C509JW , PIC16C505JW , PIC16C711JW , PIC16CE625JW
PIC18F458 , PIC18F4320 , PIC18LF258 , PIC18F4539 , PIC18F4431
Atmel Flash Memory
(Sector Programming)
(Software Data Protection)
AT29C256, AT29C512,AT29C010A, AT29C020, AT29C040,AT29C040A
W29EE512,W29EE011, W29EE012, W29C020(128),W29C040
PH29EE010(W29EE011)
ASD AE29F1008 (AT29C010), AE29F2008 (AT29C020)
Ver 0.992 up(DOS). Can run under win9x
(disable prog. CPUIdle or CPUCool)
Atmel Flash Memory
AT49Fxxx (Subset 29Fxxx)
(Byte-by-Byte Programming)
(Software Data Protection)
Command seq. 5555/AA, 2AAA/55, 5555/A0
AT49F512, AT49F010, AT49F020, AT49F040
SST39SF010, SST3S9F020 ,SST39SF040
AT49F001,AT49F002 , AT49F008A
Command seq. 555/AA, 2AA/55, 555/A0
Am29F512, Am29F010, Am29F020, Am29F040,HY29F080
29F002, 29F002T, Pm29F002T
Serial Peripheral Interface (SPI)
EEPROM Mode0 (0,0)
AT25xxx, W95xxx
[Atmel] AT25010,020, 040 (A8-A0)
AT25080, 160, 320, 640, 128, 256 (A15-A0)
[ST] W95010....256, Microchip 25x010 - 25x640
--- Byte programming
25010,25020,25040
--- Page programming
25C080,25C160,25C320,25C640,25C128,25C256,25C512
AT25HP256,AT25HP512
AT25HP1024 (24bit address)
-- CAT64LCxxx (16bit DATA IN/OUT) use Socket 93Cxxx
CAT64LC010, CAT64LC020, CAT64LC040
Atmel EEPROM (page prog.)
(Software Data Protection)
AT28C256, AT28C010, AT28C040
Nonvaltile SRAM (DS12xx)
DS1220,DS1225Y, DS1230Y/AB, DS1245Y/AB, DS1249Y/AB
static RAM (Test RAM)
6116, 6264, 62256, 62512, 628128
EPROM winbond,SST
Electrical Erase Chip
W27E512, W27E010, W27C010, W27C020, W27C040
SST27SF256, SST27SF512, SST27SF010, SST27SF020
MX26C4000
Vcc = 3.3-3.6V SST37VF512, SST37VF010, SST37VF020, SST37VF040
Flash Memory SST,Sanyo
SST28SF040A ,LE28F4001
Adapters
Atmel AT89Cxx (MCS-51)
Adapter 32pin to MCS-51
Atmel Auto Setect
AT89C51,52,55, AT89LV51,52,55
AT89S8252 (8K+2K), AT89S53, AT89LS8252,AT89LS53
AT89C1051,AT89C2051,AT89C4051 (20pin)
AT89C51RC (32KB), AT89C55WD (6.2V)
SST89C54/58, SI89C52
Intel Auto Select
i87C51, i87C51FA, i87C51FB
------------------------------------------------
i8xC51,i8xC52,i8xC54,i8xC58 (tWP = 100uS*25 Pulse)
Atmel AVR 8-bit RISC AT90Sxxx
(Parallel programming)
Adapter 32pin to MCS-51
(read, write, erase, verify, check empty, lockbits, fusebits) [Flash memory/EEPROM]
AT90S1200,AT90S2313
90S2333, 90S4433, 90S4414, 90S8515, 90S4434, 90S8535
reference AT90S2313 pin
Function lockbitread AT90S2313 Errata Sheet.pdf
MCS-48,MCS-41
Adapter 32pin to MCS-48/41
ROM (read/verify)
P8048AH, P8049AH,P8050AH, P8042AH Vea = 12V
P8041, P8042
OTP (read/verify/program)
P8748,P8749H,P8742HVea = 18V
EPROM (read/verify/program)
D8748,D8749,D8742,D8741, D8742 Vea = 18V
FLASH memory 8/16bit
(Software Data Protection)
Adapter (TSOP48)
Am29F400,Am29F800,29F160,29F320 (read, write byte mode)
HY29F200, HY29F400, HY29F800 , AT49F2048A, AT49F4096A, AT49F8192A
FLASH memory 8/16bit (Vpp12V)
(Software Data Protection)
Adapter (TSOP48)
i28F200,i28F400,i28F800,i28F160 (TSOP48)
28F001(DIP32 or PLCC32)
EPROM 16bit (DIP40) (1-4Mbit)
Adapter Eprom 16bit
Eprom only
27C1024 (27C210), 27C2048 (27C2002), 27C4096 (27C4002),
Schematic by Toomas Toots
(read, program byte mode
by use Resister pull up Data Bus (0xFF), A0 select low or high byte)
EPROM 16bit (DIP42) (4-32Mbit)
Adapter Eprom DIP42
Eprom only
M27C400(DIP40), 27C800, 27C160, 27C322
Schematic by Toomas Toots
(read, program byte mode
by use Resister pull up Data Bus (0xFF), A0 select low or high byte)
FLASH memory 8/16bit
(Software Data Protection)
Adapter (TSOP48LV)
29LV200, 29LV400,29LV800,29LV160,29LV320 (read, write byte mode)
Firmware Hub / LPC FLASH
Adapter Firmware Hub/LPC (PLCC32) (PP mode) (3.3V)
-- Firmware Hub
82802AB, 82802AC, AT49LW040, AT49LW080
SST49LF002A, SST49LF003A, SST49LF004A, SST49LF008A, PMC 49FL008T
W49V002FA, W39V040FA
-- LPC flash
SST49LF020, SST49LF040 W49V002A, W39V040A
WINBOND
W39V040FA, W39V040FAP, W39V040BP, W39V04OBPZ, W49V040FBPZ, W39V040FCP, W39V040FCPZ
W39V080AP, W39V080APZ, W39V080FAP, W39V080FAPZ (Newly added for software 0.98D8)
P28F002BC
Adapter P28F002BC (DIP40)
BOOT BLOCK FLASH MEMORY
- P28F002BC
